Етс 974 контроллер инструкция: Контроллер Elitech ECS -974 (2 датчика | Festima.Ru

Электронный контроллер GLORYA ETC-400D (аналог EWDR 974)

Электронный контроллер GLORYA ETC-400D (аналог EWDR 974)





Контроллеры ETC-400D – приборы для холодильных систем нормальной и низкой температуры. Они снабжены двумя входами для PTC датчиков и тремя выходными реле для управления компрессором, разморозкой и вентиляторами испарителя.





Продолжительность циклов разморозки определяется заданным временным интервалом или по достижению значением датчика испарителя температуры конца оттайки.





Прибор также снабжен зуммером для звуковой сигнализации о температурных Авариях.

Считываемое датчиком значение температуры отражается на 3-х цифровом дисплее.

Эти контроллеры выпускаются в формате модуля 4 DIN;

источник питания, по выбору, 230, 115, 24 B или 12 B.





Характеристики и параметры





  • Корпус: пластиковый модуль 4 DIN.



  • Размер: лицевая панель 70×85 мм, глубина 61 мм.



  • Монтаж: на DIN рейку (Omega 3) или на стену.



  • Подключение: винтовые клеммы для проводников с сечением до 2,5 мм.



  • Дисплей: 3-х цифровой, высота 12,5 мм



  • Сохранение данных: энергонезависимая память (EEPROM).



  • Рабочая температура: –5…60 °C.



  • Температура хранения: –30…75 °C.



  • Входа: 2 входа под PTC датчики для регулирования температуры камеры и окончания разморозки.



  • Выхода: 3 выхода: для компрессора реле типа SPST на 8(3)А 250B, для разморозки реле типа SPDT на  8(3)А 250B и для вентиляторов испарителя реле типа SPST на 8(3)А 250B.



  • Разрешение: 1°C.



  • Точность: не хуже 0.5% от шкалы.



  • Источник питания: 12 B  ±15%, или 24, 115, 230 B ±10%, 50/60 Гц.










Электронный контроллер Danfoss ERC 213 – Контроллеры (электронные блоки управления) –

Комплектация с датчиками

Danfoss ERC 213 – это многофункциональный контроллер охлаждения с управлением температурой и оттаиванием, он разработан для удовлетворения современных требований в области систем охлаждения на торговых предприятиях. ERC 213 имеет три релейных выхода и четыре входа (2 аналоговых, 1 аналоговый/цифровой, 1 цифровой). Выходы: реле 1 – управление компрессором/электромагнитным клапаном, реле 2 – можно настроить на оттаивание или внешний сигнал тревоги, реле 3 – управление вентилятором. Входы: вход 1 – управляющий датчик (Sair), вход 2 – температурный датчик оттайки (S5), вход 3 – датчик конденсатора (Sc) или цифровой вход, вход 4 – цифровой вход, который может быть настроен на различные функции.

Электропитание 115В/230В перем.тока
Номинальная мощность Менее 0,7 Вт
Входные сигналы 4 входа – 2 аналоговых, 1 аналоговый/цифровой и 1 цифровой
Разрешенные типы датчиков NTC 5000 Ом при 25 °C
NTC 10 000 Ом при 25 °C
PTC 1000 Ом (EKS 111)
Pt1000
Датчики, включенные в комплект решения NTC 10000 Ом при 25 °C, длина кабеля =1,. 5 м
Точность Диапазон измерений:
от -40 до 105 °C (от -40 до 221 °F)
Точность регулятора:
+/-1 K ниже -35 °C, +/-0.5 K от -35 до 25 °C,
+/-1 K выше 25 °C
Выход Реле компрессора DO1:
16 A, 16 (16) A, EN 60730
10 FLA/60 LRA при 230 В, UL60730
16 FLA/72 LRA при 115 В, UL60730
Реле оттаивания DO2:
8 A, 2 FLA/12 LRA, UL60730
8 A, 2 (2 A), EN60730
Реле вентилятора DO3:
3 A, 2 FLA/12 LRA, UL60730
3 A, 2 (2 A), EN60730
Дисплей Светодидный дисплей, 3 цифры, десятичная запятая
Условия работы от -10 до 55 °C (от 14 до 131 °F), относительная влажность 90%
Условия хранения от -40 до 70 °C (от -40 до 158 °F), относительная влажность 90%
Защита Передняя сторона: IP65 (встроенная прокладка)
Задняя сторона: IP00
Окружающая среда Степень загрязнения II, без конденсации
Тепло- и огнестойкость Категория D (UL94-V0)
Категория ЭМС Категория I
Сертификация UL признание (US & Canada) (UL 60730)
ENEC (EN 60730)
CQC
CE (LVD & EMC Directive)
EAC (GHOST)
NSF
ROHS2. 0
Температурный мониторинг HACCP в соответствии с EN134785 Class I,
когда используется датчик AKS 12

Удобство использования – четыре кнопки, простая структура меню, предварительно установленные приложения обеспечивают превосходное удобство использования.

Простота установки – высокопроизводительное реле 16 А позволяет прямое подключение больших нагрузок, например компрессоры 2 л.с., без использования промежуточных реле. Большой диапазон совместимых типов датчиков и клеммы винтового соединения обеспечивают высокую гибкость при установке.
Защита установки – такие специальные функции программного обеспечения, как защита компрессора от колебания электропитания или от высокой температуры конденсации обеспечивают безопасность эксплуатации установки.
Энергоэффективность – оттаивание по мере необходимости, дневной-ночной режим и интеллектуальное управление вентилятором испарителя обеспечивают энергоэффективность.
Защита по низкому и высокому напряжению путем ограничения работы компрессора в указанных пределах напряжения. Если напряжение выходит за указанные пределы, контроллер отключает компрессор и на дисплее начинает мигать сигнализация. Он вернется к работе, когда напряжение вернется в пределы рабочего диапазона с учетом минимального времени остановки.
Если конденсатор заблокирован загрязнениями и, следовательно, температура конденсации сильно повышается, контроллер активирует предупредительную сигнализацию и, если температура продолжит повышаться, отключает компрессор. Если температура, измеренная датчиком конденсатора (Sc), достигает заданного ”предела предварительной сигнализации”, активируется авария для предупреждения пользователя о наличии проблем с конденсатором. Часто причиной является ограничение потока воздуха через конденсатор (загрязнение) или поломка вентилятора конденсатора. Сигнализация сбрасывается при снижении температуры конденсатора на 5 °C. Если измеряемая температура конденсатора продолжает расти и достигает заданного “предела блокировки”, компрессор останавливается и не запускается до тех пор, пока сигнализация не будет сброшена вручную.

Назначение предварительно заданных применений заключается в том, чтобы предоставить пользователю простой и быстрый способ настройки контроллера в зависимости от температуры хранения (НТ, СТ, ВТ), типа оттаивания (отсутствует, естественное, электрическое) и метода оттаивания (завершение по времени или температуре).После того, как пользователь выбирает применение на основании требований, контроллер загружает определенный набор значений параметров и скрывает те параметры, которые не актуальны для выбранного применения. Настроенное значение параметра можно изменить в любое время. В дополнение к предопределенные приложения, все версии контроллера имеют две стандартные приложения, один с полным списком параметров, а другой с упрощенной списка параметров, что позволяет пользователю сделать свои собственные пользовательские настройки параметров (AP0 и AP6 в случае ERC213/ERC214).
